Android SDK

Learn how to use the Android version of our mobile SDK to quickly integrate our Payments product into your app.

🚧

This feature is in private beta and is currently available to a limited number of customers. To join our private beta, contact Client Care.

With the TrueLayer SDK for Android, you can quickly add open banking payments to your app. Our Android SDK integrates with TrueLayer's Payments API, making it simple to get up and running.

Image of what the native screens look like on an Android device. There are two screenshots in the image, one shows the bank selection screen and the other shows the payment confirmation screen.Image of what the native screens look like on an Android device. There are two screenshots in the image, one shows the bank selection screen and the other shows the payment confirmation screen.

Image of what the native screens look like on an Android device. There are two screenshots in the image, one shows the bank selection screen and the other shows the payment confirmation screen.

The Android SDK presents native screens that allows your users to select their bank and consent to the payment. Then, it redirects them to their banking app or website to authorise the payment. It also handles network requests and errors and gives you some options to customise the user interface.

Compatibility

The SDK is designed to work with Android 7.0 (API level 24) and above.

Payment journey

  1. The user selects Pay By Bank.
  2. Your app creates creates a payment on the backend side.
  3. Your backend integration creates a payment and gets a payment resource back.
  4. Your app gets the payment_id and resource_token back and initialises the SDK.
  5. Your user selects and confirms their bank on the screen of the mobile SDK.
  6. The mobile SDK redirects your user to their bank's website or app.
  7. Your user authorises the payment in their bank's website or app.
  8. Once the authorisation is complete, the bank redirects the user to your redirect_url.
Image containing a diagram that shows the payment journey with mobile SDK integration.Image containing a diagram that shows the payment journey with mobile SDK integration.

Image containing a diagram that shows the payment journey with mobile SDK integration.

Before you begin

Before you can use the SDK, you have to:

  1. Create a payment using the Payments API v3.
  2. Register a redirect_uri from our developer console. Use at the end of the payment journey to redirect back to your website or application.

Step 1: Install the SDK

To add the SDK to your project, simply include TrueLayer Payments SDK to your dependencies. The SDK is hosted on the TrueLayer Artifactory server, so follow the instructions below to add it to your project repository list.

// Add to your projects `build.gradle`.
implementation "com.truelayer.payments:ui:0.0.36"

In your main Gradle file (root project build.gradle) you need to add the TrueLayer Artifactory. You have two options for how to do this:

Option 1: Use local.properties file

def localProperties = new Properties()
try {
    localProperties.load(new FileInputStream("local.properties"))
} catch(Exception e) {
    // local properties only required to pull artifacts from
    // truelayer.jfrog.io. At the moment this will only be done
    // on developers machines but not on CI.
    println("File local.properties is not available. Fetching from truelayer.jfrog.io" +
    " will not be possible.")
}

allprojects {
    repositories {
        maven {
            url 'https://truelayer.jfrog.io/artifactory/maven-local'
            credentials {
                username "${localProperties['artifactory.username']}"
                password "${localProperties['artifactory.apikey']}"
            }
            content {
                // this repository *only* contains artifacts with group "com.truelayer"
                includeGroupByRegex "com\\.truelayer.*"
            }
        }
        google()
        jcenter()
        mavenCentral()
    }
}

Then in your local.properties file, add the following lines:

[email protected]
artifactory.apikey=Your-Artifactory-API-Key

Option 2: Store the username and apikey directly in the Gradle file

allprojects {
    repositories {
        maven {
            url 'https://truelayer.jfrog.io/artifactory/maven-local'
            credentials {
                username [email protected]
                password Your-Artifactory-API-Key
            }
            content {
                // this repository *only* contains artifacts with group "com.truelayer"
                includeGroupByRegex "com\\.truelayer.*"
            }
        }
        google()
        jcenter()
        mavenCentral()
    }
}

Step 2: Initialise the SDK

To use the SDK, you have to first initialise it before invoking any other SDK method. The following code sample is an example of initialising the SDK:

import com.truelayer.payments.core.domain.configuration.Environment
import com.truelayer.payments.core.domain.configuration.HttpConnectionConfiguration
import com.truelayer.payments.core.domain.configuration.HttpLoggingLevel
import com.truelayer.payments.ui.TrueLayerUI

// Initialize the SDK with your application context.
TrueLayerUI.init(context = applicationContext) {
    // optionally choose which environment you want to use: PRODUCTION or SANDBOX
    environment = Environment.PRODUCTION
    // Make your own custom http configuration, stating custom timeout and http request logging level
    // Logs will only be written in DEBUG version of the SDK
    httpConnection = HttpConnectionConfiguration(
        timeoutMs = 5000,
        httpDebugLoggingLevel = HttpLoggingLevel.Basic
    )
}

Step 3: Process a payment

Depending on your preferred approach, you can choose to integrate the SDK into your payment process with either AndroidX Activity, with the old-fashioned Android Activity or with Jetpack Compose.

In both cases, you'll need the paymentId and the resourceToken obtained from the backend.

Option 1: Process a payment with an AndroidX Activity integration

import com.truelayer.payments.ui.models.PaymentContext
import com.truelayer.payments.ui.screens.coordinator.FlowCoordinatorActivityContract
import com.truelayer.payments.ui.screens.coordinator.FlowCoordinatorResult

// Register for the end result.
val contract = FlowCoordinatorActivityContract()
val flowResult = registerForActivityResult(contract) {
    val text = when (it) {
        is FlowCoordinatorResult.Failure -> {
            "Failure ${it.reason}"
        }
        is FlowCoordinatorResult.Successful -> {
            "Successful ${it.step}"
        }
    }
    // present the final result
    Toast.makeText(this, text, Toast.LENGTH_LONG).show()
}

// Obtain your payment context from your backend
val paymentContext = PaymentContext(
    paymentId =  "your-payment-identifier",
    resourceToken = "payment-resource-token",
    redirectUri = "redirect-uri-that-will-be-invoked-when-coming-back-from-bank"
)

// 🚀 Launch the payment flow.
flowResult.launch(paymentContext)

Option 2: Process a payment with an Android Activity integration

import android.app.Activity
import android.content.Intent
import android.os.Bundle
import android.widget.Toast
import com.truelayer.payments.core.domain.configuration.Environment
import com.truelayer.payments.ui.TrueLayerUI
import com.truelayer.payments.ui.models.PaymentContext
import com.truelayer.payments.ui.screens.coordinator.FlowCoordinatorActivityContract
import com.truelayer.payments.ui.screens.coordinator.FlowCoordinatorResult
import com.truelayer.samplepayment.Configuration
import com.truelayer.samplepayment.databinding.ActivityMerchantBinding

class ActivityIntegration : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)

        // Initialise the payments configuration
        TrueLayerUI.init(context = applicationContext) {
            environment = Environment.PRODUCTION
            httpConnection = Configuration.httpConfig
        }

        // Obtain your payment context from your backend
        val paymentContext = PaymentContext(
            paymentId =  "your-payment-identifier",
            resourceToken = "payment-resource-token",
            redirectUri = "redirect-uri-that-will-be-invoked-when-coming-back-from-bank"
        )
        // Create an intent to launch the SDK
        val intent = FlowCoordinatorActivityContract().createIntent(this, paymentContext)
        // Launch the SDK
        startActivityForResult(intent, 0)
    }

    override fun onActivityResult(requestCode: Int, resultCode: Int, data: Intent?) {
        super.onActivityResult(requestCode, resultCode, data)
        // Act on the SDK result
        val text = when (val result = FlowCoordinatorResult.unwrapResult(data)) {
            is FlowCoordinatorResult.Failure -> "Failure ${result.reason}"
            is FlowCoordinatorResult.Successful -> "Successful ${result.step}"
            null -> "Activity result failed."
        }
        Toast.makeText(this, text, Toast.LENGTH_LONG).show()
    }
}

Option 3: Process a payment with a Jetpack Compose integration

You have to make sure that you have setDecorFitsSystemWindows(window, false) and window.setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_RESIZE) set for the Activity that will be hosting SDK Compose code. The following example shows how to process a payment with a Jetpack Compose integration:

// place the following code in your `onCreate` method of the activity hosting compose code
override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)

    // The following lines are required for the accompanist-ui-insets
    // to work properly
    WindowCompat.setDecorFitsSystemWindows(window, false)
    @Suppress("DEPRECATION")
    window.setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_RESIZE)

}

// Your payments custom theme or use the provided defaults as below
val theme = TrueLayerTheme(
    lightPalette = LightColorDefaults,
    darkPalette = DarkColorDefaults,
    typography = TypographyDefaults
)

// Obtain your payment context from your backend
val paymentContext = PaymentContext(
    paymentId =  "your-payment-identifier",
    resourceToken = "payment-resource-token",
    redirectUri = "redirect-uri-that-will-be-invoked-when-coming-back-from-bank"
)

setContent {
    Theme(
        theme = theme
    ) {
        FlowCoordinator(
            paymentContext = paymentContext,
            onSuccess = { successStep ->
                // action on success
            },
            onFailure = { failureReason ->
                // action on failure
            },
        )
    }
}

Customise colours

Currently, colour customisation is only available when integrating via Jetpack Compose. To change colours or typography, you have to provide your own version of LightColorDefaults, DarkColorDefaults, TypographyDefaults. You can use .copy() to override just a single colour. For example:

TrueLayerTheme(
    lightPalette = LightColorDefaults.copy(primary = Color.Red),
    darkPalette = DarkColorDefaults.copy(primary = Color.DarkGray),
    typography = TypographyDefaults
)

To find a full list of colours you can override, you can check out the details of androidx.compose.material.Colors in the Android reference documentation.
